RAM from Taylor R200 – Frozen Food Dispenser

6 Basket

Description

Dispenses and stores frozen fries directly into fryer basket. Ensuring that the fries are cooked from frozen, results in improved product quality, consistency and yield.

Product Specifications

Taylor

FEATURES	FEATURES Dispenses and stores frozen fries directly into fryer basket. Ensuring that the fries are cooked from frozen, results in improved product quality, consistency and yield. Unit is designed for simple daily cleaning of cabinet and refrigeration filter. Provides storage of up to two baskets, flexible store configuration for left or right hand door opening. Self contained environmentally friendly refrigeration system using R290 with cold wall construction. DISPENSING Portion control dispensing system enables the operator to fill one basket and slide another basket back into the fill position. An electronic weighing system allows for a portion-controlled fill level for the basket. Provides visual indication when product in the hopper is low or empty. Unit incorporates an inductive sensor to ensure proper basket placement prior to dispensing. OPERATION Operation of the R200 Frozen Food Dispenser is easily controlled by a power switch, portion control keys and a series of menu functions located on the operator control panel. The LED control display is used for calibration, and system diagnostics. The portion control keys are used to select the desired basket load weight and will alert crew when the hopper is empty.
FINISHED PRODCUTS	6 Baskets
INSTALLATION	Floor
NUMBER OF FLAVORS	One, R290
FREEZING CYLINDER QTY	Minimum 4 in. (101.6 mm) rear, and 2 in. (508 mm) side clearance
FREEZING CYLINDER SIZE	8 ft. (2.43 m)
HOPPER SIZE (QT/L)	NA
HOPPER QTY	NA
MIX DELIVERY SYSTEM	NA
REFRIGERATION CONTROL	NA
DIMENSIONS W/D/H (IN/MM)	22-1/2 (w) 57 cm (w) 31 " (d) 79 cm (d) 76-3/4 " (h) 195 cm (h)
NET WEIGHT (LBS/KG)	339 lbs (154 kg)
